Micrometer head S_Head EVO Smart
Starting at :
Description
Micrometer head with integrated Bluetooth® technology. To be mounted on big goose-neck.
Features
- Advanced Connectivity: Benefit from seamless data output via Bluetooth®, ensuring efficient data transfer.
- Reliable and Durable: Built to withstand demanding environments, our micrometric head provide IP65 protection.
Applications
Distance
Industries
Automotive
Aeronautics
Packaging
Machine tool
Overview
Specifications
Standard Delivery
Accessories
Applications
Tutorials
Documents
| 803-6500 | |
| EAN | |
| Measuring range (mm) | 30 |
| Max. error MPEJ (µm) | 3 |
| Repeatability MPER (µm) | ≤ 1 |
| Resolution (mm) | 0.0001 |
| Measuring force (N) | 5 – 10 |
| Protection rating according to IEC 60529 | IP65 |
| Connection type (instrument to device) | Bluetooth® wireless technology ¹ |
| PRESET function | ⬤ |
¹ Device: PC, display unit, …
Spécifications
| 803-6500 | |
| EAN | |
| Measuring range (mm) | 30 |
| Max. error MPEJ (µm) | 3 |
| Repeatability MPER (µm) | ≤ 1 |
| Resolution (mm) | 0.0001 |
| Measuring force (N) | 5 – 10 |
| Protection rating according to IEC 60529 | IP65 |
| Connection type (instrument to device) | Bluetooth® wireless technology ¹ |
| PRESET function | ⬤ |
¹ Device: PC, display unit, …
Standard Delivery
| Standard Delivery |
| Instrument according to technical specifications |
| Lithium battery CR2032 included |
| Quickstart |
