Bore gauges Xtreme 3 Holematic Smart
Description
Digital bore gauge with integrated Bluetooth® technology – pistol type with quick retraction handle.
* Available in different measuring ranges
* Available in different measuring ranges

Resolution: 1µm

Smart Inductive System (SIS)

Proximity output
Features
- Seamless data acquisition: Our bore gauge is equipped with integrated Bluetooth® technology, allowing you to transmit measurements wirelessly, quickly and error-free for enhanced productivity.
- Unmatched Accuracy: Display resolution of 0.001 mm with a digit height of 9 mm, providing precise measurements that meet the highest metrology standards.
- Enhanced Measuring Capabilities: With a measuring range from 2 to 300mm and blind bore measurement capabilities from 2-6 mm and 12.5 mm, this bore gage caters to a wide range of measurement requirements, offering unparalleled adaptability.
- User-Friendly & flexible Design: Interchangeable measuring heads with hard metal 2 points (Ø 2 to 6 mm) and 3 points (from Ø 6 mm) contact points, allowing you to adapt to various applications effortlessly.
- Built to Last: This gauge is designed to withstand heavy-duty work with a protection rating of IP67, even when connected.
- Complete Package: Each instrument comes with a wooden box containing all the necessary items, calibration rings, and UKAS certificates, providing everything you need for accurate measurements.
Applications

Diameter
Industries

Automotive

Aeronautics

Packaging

Machine tool
Overview
Specifications
Standard Delivery
Accessories
Applications
Tutorials
Documents
954-6006 | 954-6007 | 954-6008 | 954-6009 | 954-6010 | |
EAN | 7640125714432 | 7640125714449 | 7640125714456 | 7640125714463 | 7640125714470 |
Type | XT3H BT 1M | XT3H BT 2M | XT3H BT 3M | XT3H BT 4M | XT3H BT 5M |
Measuring range (mm) | 2 – 2.5 | 2.5 – 3 | 3 – 4 | 4 – 5 | 5 – 6 |
Depth | 9 | 12 | 18 | ||
Max. error (µm) | 4 | ||||
Ø Incl. ring (mm) | 2.5 | 4.0 | 5.0 | ||
Connection type (instrument to device) | Bluetooth® wireless technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
954-6011 | 954-6012 | 954-6013 | 954-6014 | 954-6015 | |
EAN | 7640125714487 | 7640125716696 | 7640125710809 | 7640125710793 | 7640125710816 |
Type | XT3H BT 6M | XT3H BT 8M | XT3H BT 10M | XT3H BT 12M | XT3H BT 16M |
Measuring range (mm) | 6 – 8 | 8 – 10 | 10 – 12.5 | 12.5 – 16 | 16 – 20 |
Depth | 58 | 62 | |||
Max. error (µm) | 4 | ||||
Ø Incl. ring (mm) | 8.0 | 12.5 | 12.5 | 20.0 | |
Connection type (instrument to device) | Bluetooth® wireless technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
954-6016 | 954-6017 | 954-6018 | 954-6019 | 954-6020 | |
EAN | 7640125710823 | 7640125710830 | 7640125710847 | 7640125710854 | 7640125710861 |
Type | XT3H BT 20M | XT3H BT 25M | XT3H BT 35M | XT3H BT 50M | XT3H BT 65M |
Measuring range (mm) | 20 – 25 | 25 – 35 | 35 – 50 | 50 – 65 | 65 – 80 |
Depth | 66 | 80 | |||
Max. error (µm) | 4 | 5 | |||
Ø Incl. ring (mm) | 20.0 | 35.0 | 65.0 | ||
Connection type (instrument to device) | Bluetooth® wireless technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
954-6021 | 954-6022 | 954-6023 | 954-6024 | 954-6025 | |
EAN | 7640125710878 | 7640125710885 | 7640125710892 | 7640125710908 | 7640125710915 |
Type | XT3H BT 80M | XT3H BT 100M | XT3H BT 125M | XT3H BT 150M | XT3H BT 175M |
Measuring range (mm) | 80 – 100 | 100 – 125 | 125 – 150 | 150 – 175 | 175 – 200 |
Depth | 85 | 100 | |||
Max. error (µm) | 5 | 6 | 7 | ||
Ø Incl. ring (mm) | 80.0 | 125.0 | 175.0 | ||
Connection type (instrument to device) | Bluetooth® Wireless Technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
954-6026 | 954-6027 | 954-6028 | 954-6029 | |
EAN | 7640125710922 | 7640125710939 | 7640125710946 | 7640125710953 |
Type | XT3H BT 200M | XT3H BT 225M | XT3H BT 250M | XT3H BT 275M |
Measuring range (mm) | 200 – 225 | 225 – 250 | 250 – 275 | 275 – 300 |
Depth | 100 | 103 | ||
Max. error (µm) | 8 | 9 | ||
Ø Incl. ring (mm) | 225.0 | 275.0 | ||
Connection type (instrument to device) | Bluetooth® wireless technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
955-6001 | 955-6002 | 955-6003 | 955-6004 | |
EAN | 7640125710960 | 7640125710977 | 7640125710984 | 7640125710991 |
Measuring range (mm) | 2 – 6 | 6 – 20 | 20 – 100 | 100 – 300 |
Type | XT3PG BT 01M | XT3PG BT 02M | XT3PG BT 03M | XT3PG BT 04M |
Thread | 1/4‘‘ x 40 TPI | 5/16‘‘ x 40 TPI | 5/8‘‘ x 24 TPI | |
Connection type (instrument to device) | Bluetooth® wireless technology ¹ Proximity to RS232 ¹ Proximity to USB ¹ Adaptator RS – USB ¹ View cables info |
¹ Device: PC, display unit, …
Standard Delivery
|
Instrument according to technical specifications |
Wooden box ( XT3H : from 200 mm = 2 box) ¹ |
Rings according to technical specifications + UKAS certificate |
1 x digital display XT3PG |
Lithium battery CR2032 included |
Instruction manual |
Calibration certificate |
¹ Fumigated compatible ISPM 15 and NIMP 15
-
Solutions to special internal measurements
Special Bowers/Sylvac Bore Gauges XT
-
-
-
-
- Technical Plan
- 3D Drawing
- Manual
- Certificate
- Brochure
