We are pleased to officially announce the launch of our newย ๐๐๐๐ง ๐๐๐ ๐จ๐ฉ๐ญ๐ข๐๐๐ฅ ๐ฆ๐๐๐ฌ๐ฎ๐ซ๐ข๐ง๐ ๐ฆ๐๐๐ก๐ข๐ง๐, designed to push the boundaries of dimensional metrology in the most demanding production environments.
The Scan S65 is the direct successor to the F60, offeringย more features and a larger measuring rangeโat the same price. It brings major improvements in speed, repeatability, flexibility, and automation integration, fully aligned with Industry 4.0 requirements.
๐๐ก๐๐ญโ๐ฌ ๐ง๐๐ฐ ๐ฐ๐ข๐ญ๐ก ๐ญ๐ก๐ ๐๐๐๐ง ๐๐๐?
Here are the key highlights of this next-generation machine:
– Significantly faster measurements: scanning speed increased byย +60%, rotation speedย doubled
– Enhanced repeatability: improved fromย 1.8โฏยตm (length)ย on the F60 toย <1.0โฏยตm (length)ย on the new S65
– Increased length capacity: improved from 300mm/500mm (length) on the F60/L to 350mm/700mm (length) on the new S65/L
– Sylvacโs exclusive Tilt system: for advancedย thread measurement
– Motorized tailstock: essential for fullย automation integration
– Adjustable clamping force: adaptable to any type of part
– Interior LED lighting: for improved setup visibility
– Top-loading capability (crane/hoist compatible): ideal for heavy parts
– Supports parts up to 60 kg
– 8โ touchscreen interface: simple, fast, and user-friendly operation
– Quick-release tooling (ISO): for rapid part changeovers
